RMX / RMX - T Precision / Heavy Duty Rod Ends 3 - Piece , Metal to
Metal or PTFE Lined , Heat Treated Alloy Steel
Product Description
The RMX/RMX-T Series rod ends feature a reinforced 3-piece alloy
steel body with step shank design, engineered for heavy-load
industrial and racing applications. The RMX-T variant integrates a
permanently bonded PTFE liner to minimize wear, reduce maintenance,
and extend service life in high-stress environments. Constructed
with thru-hardened bearing-grade steel balls (precision-ground for
optimal fit) and heat-treated alloy steel body/race components,
these rod ends deliver 30% higher radial/axial strength vs.
standard designs. Zinc plating and clear chromate finish ensure
corrosion resistance and an aesthetic bright-metal appearance for
exposed surfaces.
Technical Parameters
| Product Name | RMX/RMX-T Precision/Heavy Duty Rod Ends |
| Specification | 3-Piece, Metal to Metal or PTFE Lined, Heat Treated Alloy Steel,
Heavy Duty Shank |
| Material | Ball –
• 52100 Steel
• Rc 56 Min.
• Hard Chrome Plated
Body –
• Alloy Steel, Heat Treated
• Zinc Plated, Clear Chromate Treated
Race RMX–
• Alloy Steel, Heat Treated
• Zinc Plated, Clear Chromate Treated
Race RMX-T–
• Low Carbon Steel
• Zinc Plated, Clear Chromate Treated
Liner RMX-T only – • PTFE Fabric,Permanently Bonded to I.D. |
| Features | • 3-piece alloy steel body design provides for maximized
strength(PTFE lined version
also available)
• Increased resistance to radial static load capacity via heavy
duty step shank design
• Larger housing design for even heavier loads
• Precision spherical bearing insert allows for optimum contact
between the ball and race extending the product life
• Can be used in a wide range of temperatures:-65°F — 250°F(-54°C —
121°C)
• Offered in studded and right or left-handed versions
• Custom assemblies can be built to your specifications
• English sizing and male styles only |
| Brochure | Free samples are available if all sizes are the same as what we
have available, if not, please contact me for a cost effective
solution |
| Belivery Time | 7-40 working days |
| Applications | Heavier load, higher precision motion control devices and
applications, including:
• Wide range of industrial equipment
• Racing |
| Documentation | rod-ends
RMX-RMX-T pdf.pdf |
Chart Notes: 1. For standard lubrication fitting, add "Z" to
suffix. Example: RMX10Z
2. This series is also available in a studded configuration.
Specify by adding "S" to suffix. Example: RMX10S
Real Picture
OEM/ODM
Production Process
Packing and Shipping
A.Packing
Usually according to the specific size of the product to arrange
the packaging, small goods are packed in cardboard boxes, large
goods are packed in cardboard boxes + wooden pallets, or one-piece
paper pallets, if you have special needs, please contact us, we
will try our best to serve you!
cardboard boxes (small goods) | cardboard boxes+wooden pallets (large goods) | one-piece paper pallets (large goods) |
 |  |  |
B.Shipping
We have cooperated with the world's major logistics companies, you
can choose the logistics mode that suits your needs, so that the
goods can arrive within the specified time.
| Logistic Company |  |  |  |  |  |
| Mode of Transportation | Land, sea and air transportation |
C.Payment Methods
Note:If you need another payment method, please contact us.
About us
Your Professional Control Cable Manufacturer!
Phidix Motion Controls (PMC) started the business in 2004,CMC
Provides a diverse range of high-end drive control products and
engineered solutions. The product line includes various sizes of
control flex shafts, cab units and a range of standard parts for a
wide range of high-end industrial customer markets.
| Why choose us |
Patent Certificate | Reasonable Prices |
The company's products have passed the IATF16949 patent
certificate, which ensures the quality of the products. | High quality + factory price + fast response+reliable service is
what we try our best to provide for you. |
Rapid Delivery | ODM/OEM |
We have all the styles you need in stock and can deliver on short
notice. | When you make a request, our engineers provide you with a faster
and better solution based on your needs. |
FAQ
Q: How do you design control cables?
A: We must first understand your application and must consider many
factors, such as length, outside diameter, working input force,
maximum input force, travel, housing material, requirements for the
wire rope, material of the terminal fittings (carbon steel or
stainless steel), etc.
Q: How do I place my order?
A: We produce according to the specifications, drawings or samples
provided by the customer.
Q: Is the quality of your product good? How can I trust you?
A: We are a professional manufacturer of wire assemblies with more
than 10 years of production experience in China. We have been
providing first-class service and quality products to make our
customers successful. Please contact our sales department and let
us know what we can do for you, trust us, we won't let you down.
Q: What is the lead time for my order?
A: This depends a lot on the size of your order. Usually 15 days.
If you need it urgently, we will do our best to fulfill your
request.
