COM - T Series Spherical Ball Bearing Low Carbon Steel , PTFE Lined
Product Description
A cost-effective solution for non-rotational applications, the
COM-T Series combines a PTFE-lined inner race with a thru-hardened
52100 steel ball (hard chrome plated) for durability. Designed for
press-fit installations on plate-mounted OEM/MRO equipment, these
bearings feature a low-carbon steel race oil-coated post-assembly
to ensure optimal ball-to-race conformity and reduced wear. The
PTFE liner minimizes friction and extends service life,
outperforming standard metal-to-metal designs. Ideal for
low-maintenance, high-load environments where rotational motion is
absent. Custom sizes and metal-to-metal versions available for
specialized requirements.
Technical Parameters
| Product Name | COM - T Series Metal Ball Bearings |
| Specification | Low Carbon Steel,PTFE Lined
|
| Material | Ball- • 52100 Steel • Rc 56 Min. • Hard Chrome Plated Race- • Low Carbon Steel • Oil Coated Liner- • PTFE Liner, Permanently Bonded to Race I.D. |
| Features |
• Suited for numerous non-rotational applications — for mounting into plates or shocks where room for attaching full rod ends is not available
• PTFE lined design minimizes friction between working surfaces (lower maintenance, increased life)
• Low carbon steel design provides for lower cost alternative
• Can be used in a wide range of temperatures: -65°F - 250°F (-54°C - 121°C)
|
| Brochure | Free samples are available if all sizes are the same as what we
have available, if not, please contact me for a cost effective
solution |
| Belivery Time | 7-40 working days |
| Applications | Numerous plate-mounted, press fit bearing applications across a
wide range of OEM and MRO markets, including: • Industrial equipment • Construction equipment • Racing |
| Documentation | COM-T_SB-05.pdf |
